TAMIYA RC GRASSHOPPER

Scale: 1/10

Chassis Type: ABS resin monocoque frame

Drive System: 2WD, rear‑mounted motor

Motor: 540‑type brushed motor (kit includes 380 motor with adapter)

Gear Ratio: 18.3:1 (fixed)

Suspension:

• Front: Independent swing axle with coil springs

• Rear: Rigid axle with coil springs

Differential: Gear type

Bearings: Plastic bushings (upgradeable to ball bearings)

Body Material: Injection‑molded ABS (classic buggy styling)

Tires:

• Front: Ribbed buggy tires

• Rear: Paddle‑style off‑road tires

Dimensions: Length 389 mm × Width 223 mm × Height 135 mm

Weight: Approx. 830 g (without battery/RC gear)

Ground Clearance: 15 mm

Wheelbase: 258 mm

Required to Complete: 2‑channel radio, steering servo, 7.2 V battery, and charger
